Water Line Stoppers & End Stops

A folding head or pivoting head linestop machine is used to temporarily stop a water pipe under live flow conditions. The machine is inserted through a hot-tapped branch fitting and expanded to seal the pipe bore. Schallert's folding heads cover pipe sizes from 8 to 84 inches with pressure ratings up to 250 psi, allowing maintenance without shutting down service.

Sealing off a water line is accomplished through a line stopping operation: hot tap the pipe, install a linestop housing over the tapped fitting, insert a folding or pivoting head through the valve, and actuate it to seal the bore. Once work is complete, a completion plug is set using a plug setter tool. Schallert provides all equipment needed for each step of this process.

Schallert Enterprises manufactures line stopping equipment for pipe sizes ranging from 8 inches up to 84 inches in diameter. The folding head range includes models for 8", 12", 14", 16", 20", 24", 42", 48", and larger pipes. Pivoting head machines are available for high-pressure and high-temperature applications across a wide size range.

Schallert's pivoting head linestop machines handle up to 450 psi at 250°F for high-pressure and high-temperature applications. Plug setters (PS0410, PS0616, PS1836) are rated to 500 psi. Folding head assemblies are rated up to 250 psi, with sealing elements typically rated up to 150 psi depending on the model selected.

Yes. Line stopping is specifically designed to isolate sections of pipeline without interrupting service to downstream customers. Schallert's folding and pivoting head machines seal the pipe bore under live pressure, allowing maintenance crews to repair, replace, or bypass pipeline sections while flow continues through the rest of the system or via a bypass connection.

Schallert's pivoting head linestop machines are available with multiple sealing element materials, including Buna-N rubber (standard), EPDM, and Viton. Each material offers different chemical and temperature resistance properties. Buna-N is suitable for most water applications, EPDM handles a broader temperature range, and Viton is recommended for aggressive chemicals and hydrocarbons found in industrial pipelines.
